Technical data | Dim. | Value |
---|---|---|
Hydraulically movable work table length | mm | 2000 |
Hydraulically movable work table width | mm | 260 |
Work table speed | m/sec | 0 - 2 |
Back table speed | m/sec | up to 0.23 |
Maximal timber thickness | mm | 160 |
Maximal work length | mm | 1600 |
Spindle speed | min-1 | 8000 |
Sanding spindle speed | min-1 | 3000 |
Motor | ||
Milling stations motor power - 2 pcs. | KW | 4 at 3000 rpm |
Sanding stations motor power - 2 pcs. | KW | 4 at 3000 rpm |
Hydraulic motor power | KW | 4 at 1500 rpm |
Total unit power | KW | 20 |
Size | ||
LxWxH | mm | 4300x2450x1850 |
Weight | ||
Net weight | kg | 1600 |
The sanding unit can be ordered with oscillating sanding belts.
